System type: 2 units, 2-way coaxial phase inversion

Transducer configuration: ferrite low frequency driver 15″×1PCS

Ferrite high frequency driver

1.75″×1PCS

Maximum sound pressure level (Pmax@1m): 126dB

Frequency bandwidth (-10dB): 55Hz-20KHz

Nominal directivity (-6dB): 90°H×90°V



Power amplifier control: built-in DSP processing, RJ485 network port, Mic/Line XLR plug, gain adjustment

Power requirements: AC220V

Output level: Class D

Power: 1250w (850W*1+450W*1)

DSP: 96KHz sampling 24 bit rate

Damping coefficient: >300 (10-400Hz, 8ohms)



Hardware specifications

Box material: 15mm (0.6″) birch plywood

Color: The default is black water-based paint, other colors can be customized according to requirements

Product size: W610mm*D475.5mm*H368.2mm

Weight (each): 23.55kg

Gross weight (single pack): 25.85kg
