System type: 1 unit direct-fired inverter box
Rated power: 1000W
Maximum power: 2000W
Peak power: 4000W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 1000W—1500W@ 8 ohms
Nominal sensitivity (1W@1m): 99 dB
Maximum sound pressure level (Pmax@1m): 129dB@1000W(132dB@2000W)
Frequency bandwidth (-10 dB): 30Hz—250Hz
Nominal directivity (-6dB): omnidirectional
Transducer configuration: low-frequency driver 18" (460mm unit 100 mm voice coil) × 1
Connector: SPEAKON NL4×2
PIN1+/2+POS.
PIN1-/2-NEG.
Box material: 15mm (0.6″) birch plywood
Color: The default is black polyurea spray, other colors can be customized according to requirements
Box size: W582mm*D520mm*H592.5mm
Weight: 39.1 kg
Gross weight (single pack): 42.3
kg
