System type: 12-unit full frequency closed type
Rated power: 480W
Maximum power: 960W
Peak power: 1920W
Nominal impedance: 8 ohms
Recommended rated output power of amplifier: 500W—1000W@8 ohms
Nominal sensitivity (1W@1m): 99dB
Maximum sound pressure level (Pmax@1m): 126dB@480W(129dB@960W)
Frequency bandwidth (-10dB): 90Hz—18.5KHz
Nominal directivity (-6dB): 90°H×20°V
Transducer configuration: full frequency driver 3″ (75mm full frequency unit 20mm voice coil) × 12
Crossover mode: -----
Connector: Standard European-style four-pin socket
Cabinet material: 12mm (0.5″) MDF board
Color: The default is black environmentally friendly water-based spray, other colors can be customized according to requirements
Box size: W118mm*D125mm*H1091mm
Weight (each): 10.7kg
Gross weight (single pack): 11.9kg
