System type: 2 units, 2 frequency division passive phase inversion
Rated power: 400W
Maximum power: 800W
Peak power: 1600W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 500W—800W@8 OHMS
Nominal sensitivity (1W@1m): 97dB
Maximum sound pressure level (Pmax@1m): 123dB@400W(126dB@800W)
Frequency bandwidth (-10dB): 56Hz-20KHz
Nominal directivity (-6dB): 40°Hor.×90°Ver.
Transducer configuration: ferrite low-frequency driver 12" (300mm unit 65mm voice coil) × 1
Ferrite high frequency driver 1.7 "(44mm voice coil)×1
Crossover mode: passive
Connector: SPEAKON NL4×2 (PIN1+/2+POS.
PIN1-/2-NEG)
Cabinet material: 15MM (0.6”) MDF
Color: The default is black paint, other colors can be customized according to requirements
Box size: W605*D417*H308.9mm
Weight (each): 16.7kg
Gross weight (single pack): 18.8kg
