System type: 2 units, 2 frequency division passive phase inversion
Rated power: 450W
Maximum power: 900W
Peak power: 1800W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 600W—900W@8 OHMS
Nominal sensitivity (1W@1m): 99dB
Maximum sound pressure level (Pmax@1m): 125dB@450w(128dB@900w)
Frequency bandwidth (-10dB): 50Hz-20KHz
Nominal directivity (-6dB): 90°Hor.×40°Ver.
Transducer configuration: ferrite low-frequency driver 15" (380mm unit 75mm voice coil) × 1
Ferrite high frequency driver 1.7 "(44mm voice coil)×1
Crossover mode: passive
Connector: SPEAKON NL4×2 (PIN1+/2+POS.
PIN1-/2-NEG)
Cabinet material: 15MM (0.6”) MDF
Color: The default is black, other colors can be customized according to requirements
Box size: W440*D465*H690mm
Weight (each): 26.15kg
Gross weight (single pack): 29.45kg
