System type: 2 units, 2 frequency division passive phase inversion
Rated power: 300W
Maximum power: 600W
Peak power: 1200W
Nominal impedance: 8 OHMS
Recommended rated output power of amplifier: 40W—600W@8 OHMS
Nominal sensitivity (1W@1m): 96dB
Maximum sound pressure level (Pmax@1m): 121dB@300W(125dB@400W)
Frequency bandwidth (-10dB): 57Hz-20KHz
Nominal directivity (-6dB): 90°Hor.×90°Ver.
Transducer configuration: ferrite low-frequency driver 10″ (250mm unit 50mm voice coil) × 1
Ferrite high frequency driver 1.3 "(34mm voice coil)×1
Crossover mode: passive
Connector: SPEAKON NL4×2 (PIN1+/2+POS.
PIN1-/2-NEG)
Cabinet material: 15MM (0.6”) MDF
Color: The default is black, other colors can be customized according to requirements
Box size: W326*D465*H690mm
Weight (each): 13.40kg
Gross weight (single pack): 15.35kg
